Test Overlay

The PTPL Video Wall Controller supports text overlay banners, enabling operators to place customizable text on input sources for quick identification and clearer operations. Font, color, and position can be adjusted to ensure visibility without blocking critical visuals. Ideal for labeling sources, displaying alerts, or adding operational notes, this feature enhances efficiency and situational awareness in demanding environments.

Video Wall Groups

The PTPL Video Wall Controller is designed for scalability, with the capability to manage up to four independent video wall groups from a single unit. Each group can operate as a standalone video wall or as part of a synchronized multi-wall system, providing unmatched deployment flexibility. Input signals can be seamlessly shared and distributed across all video wall groups, ensuring consistent content delivery. This feature is ideal for large-scale control centers, airports, broadcast hubs, and enterprises requiring centralized management of multiple visualization surfaces.

4K60Hz 4:4:4 Input Signal

The PTPL Video Wall Controller is engineered to deliver uncompromising performance for mission-critical visualization environments. It supports ultra-high definition 4K60Hz 4:4:4 input signals, ensuring pixel-perfect clarity, accurate color reproduction, and smooth motion handling. This enables video walls to present true-to-life images, whether used for control rooms, broadcast studios, corporate command centers, or immersive presentation halls.

Video wall 4K Processor for Control Room

Up to 32 Layers on Each Display

The PTPL Video Wall Controller features both Picture-in-Picture (PiP) and Picture-by-Picture (PbP) modes for versatile content display. PiP enables a secondary video window to overlay the main source, ideal for live feeds or data overlays. PbP allows multiple sources to appear side-by-side, maintaining resolution and clarity, perfect for comparisons and multi-source monitoring in real-time environments.

IP Streaming and Signal Decoding

The PTPL Video Wall Controller natively supports IP streaming signal decoding, eliminating the need for external decoder hardware. It can directly decode H.264 and H.265 video streams from IP cameras, NVRs, and other streaming devices, delivering content seamlessly to the video wall. This built-in functionality reduces system complexity, lowers costs, and ensures real-time performance. Operators can monitor live surveillance feeds, remote broadcasts, or network-based media streams with minimal latency, making it an ideal solution for control rooms, security operations centers, and enterprise monitoring applications.

PTPL XM1000 SERIES
VIDEOWALL
PROCESSORS

The PTPL-VWC Series is a high-performance modular video wall controller engineered for seamless processing of LCD and LED displays. Built on a pure-hardware FPGA architecture, it ensures ultra-low latency, reliable operation, and uncompromised image quality. The system supports 4K60Hz 4:4:4 inputs, multi-layer window processing, IP stream decoding, and flexible expansion. Designed for mission-critical applications such as control rooms, command centers, airports, and data hubs, the PTPL series guarantees 24/7 stability with redundant PSU options and hot-swappable modular cards.

Features

Supports up to 76×72 inputs/outputs with modular scalability.
Up to 4 video windows per display, with stretch, roam, overlay, PiP, PbP.
Multiple video wall groups – control up to 4 walls with one chassis.
Native IP decoding – H.264/H.265 IP camera feeds without third-party decoders.
Scrolling text banners and overlay labels for source identification.
Seamless switching between sources without black screens.
Bezel compensation for precise LCD/LED wall alignment.
Front touch panel with RS232, LAN, and Web GUI control.
Hot-swappable input/output cards with adaptive slots.
Redundant power supply units for 24/7 uptime.
Pure-hardware design – immune to OS crashes, viruses, or blue-screen errors.

Specifications
